Exhibit Lifting System 20 x 20 x 20 ft. – Ground Support

This 20′ x 20′ x 20′ Exhibit Lifting System offers robust ground support for various events including LED video walls and trade shows. Featuring easy installation and durable construction, it is ideal for large-scale applications requiring reliable performance.

$21,299.00

Add to wishlist
Compare

24 months warranty

In stock ready to ship

Technical support

Financing Available

GET A FREE QUOTE NOW!

Discover the perfect LED video wall for your project. Let’s create something amazing together. Contact us today for a free, no-obligation quote

Contact Form Demo

Description

Feature Details
Vertical Truss (12) 12″ x 12″ (290x290mm) 6.6 ft. Silver Truss
Horizontal Truss (8) 15 3/4″ x 15 3/4″ (400 x 400mm) 10 ft. Silver Truss
Ground Support (4)
Top Section (4)
Sleeve Block (4)
Outriggers & Supporters (16)
Hand Chain Hoist (4) 2 Tons / 19.6 ft
Couplers & Pins Included
15 3/4″ Truss Specifications Section square: 400 x 400mm
Main Tube: 50 x 3.0mm
Vice Tube: 25 x 2.0mm
Brace Tube: 25 x 2.0mm
Material: Aluminum Alloy 6061 – T6
12″ Truss Specifications Section square: 290 x 290mm
Main Tube: 50 x 3.0mm
Vice Tube: 20 x 2.0mm
Brace Tube: 20 x 2.0mm
Material: Aluminum Alloy 6061 – T6
Sleeve Block Dimensions Beam: 15 3/4″ x 15 3/4″ (400 x 400mm)
Pillar: 12″ x 12″ (290 x 290mm)
