| Feature | Details |
|---|---|
| Pixel Pitch | 2.97mm |
| LED Configuration | 3-in-1 SMD1515 LED |
| Pixel Density | 168 x 168 per panel |
| Panel Size | 19.68” x 19.68” x 3” (500 x 500 x 75mm) |
| Module Quantity | 4 per panel (250 x 250mm) |
| Weight per Panel | 18lbs / 8.16Kg |
| Brightness | 800 NITS |
| Viewing Angle | Horizontal 140° / Vertical 140° |
| Optimal Viewing Distance | 10ft (3m) |
| Brightness Adjustment | 0~100% (100 Levels) |
| Operating Life | 100,000 Hours |
| Protection Level | IP45 (Front and Back) |
| Control System | NovaStar Synchronous System |
| Refresh Rate | 3840Hz |
| Frame Update Frequency | 50-60Hz |
| Scan Mode | 1/28 |
| Supported Input | Composite, S-Video, Component, VGA, DVI, HDMI, HD_SDI |
| Power Supply | 100~240V 50-60Hz |
| Max Power Consumption | 140W per panel |
| Average Power Consumption | 70W per panel |
| Connections (Power/Data) | Locking Power In/Out; Data EtherCon In/Out |
