| Specification | Details |
|---|---|
| Pixel Pitch | 3.91mm |
| LED Configuration | 3-in-1 SMD2121 LED |
| Pixel Density | 128 x 128 per panel |
| Panel Size | 19.68” x 19.68” x 3” / 500 x 500 x 75mm |
| Module Quantity per Panel | 4 (250 x 250mm each) |
| Weight per Panel | 18 lbs / 8.16 Kg |
| Brightness | 1500 NITS |
| Viewing Angle | Horizontal 140° / Vertical 140° |
| Minimum Viewing Distance | 15 ft / 4.5 m |
| Brightness Adjustment | 0~100% (100 Levels) |
| Operating Life | 100,000 Hours |
| Protection Level | IP45 (Front and Back) |
| Max. Power Consumption | 120W per panel |
| Ave. Power Consumption | 60W per panel |
| Control Mode | NovaStar Synchronous System |
| Refresh Rate | 3840Hz |
| Frame Update Frequency | 50-60Hz |
| Input Support | Composite, S-Video, Component, VGA, DVI, HDMI, HD_SDI |
| Power Supply | 100~240V 50-60Hz |
