P5mm Outdoor LED Video
Click to enlarge

LED Video Wall Outdoor 15.7′ x 6.3′ P5mm Turn-key

The 15.7′ x 6.3′ P5mm Outdoor LED video wall features 10 panels, delivering exceptional resolution and brightness for large outdoor events. With its sleek design and robust build, it offers vibrant visuals and smooth motion, making it an excellent choice for impactful advertising and gatherings.

$15,000.00

Add to wishlist
Compare

24 months warranty

In stock ready to ship

Technical support

Financing Available

GET A FREE QUOTE NOW!

Discover the perfect LED video wall for your project. Let’s create something amazing together. Contact us today for a free, no-obligation quote

Contact Form Demo

Description

Specification Details
Pixel Pitch 5mm
LED Configuration 3-in-1 SMD2121 LED
Pixel Density 192 x 192 per panel
Panel Size 37.8” x 37.8” x 3.5” / 960 x 960 x 88mm
Module Quantity per Panel 18 (320 x 160mm each)
Weight per Panel 62 lbs / 30.9 Kg
Brightness 800 NITS
Viewing Angle Horizontal 140° / Vertical 140°
Minimum Viewing Distance 16 ft / 4.9 m
Brightness Adjustment 0~100% (100 Levels)
Operating Life 100,000 Hours
Protection Level IP65 (Front and Back)
Max. Power Consumption 425W per panel
Ave. Power Consumption 240W per panel
Control Mode NovaStar Synchronous System
Refresh Rate 3840Hz
Frame Update Frequency 50-60Hz
Input Support Composite, S-Video, Component, VGA, DVI, HDMI, HD_SDI
Power Supply 100~240V 50-60Hz
Additional information
Outdoor

Minimal Viewing Distance

Size
