P5mm Outdoor LED Video
LED Video Wall Outdoor 18.9′ x 9.5′ P5mm Turn-key
Click to enlarge

LED Video Wall Outdoor 18.9′ x 9.5′ P5mm Turn-key

The 18.9′ x 9.5′ P5mm outdoor LED video wall, comprising 18 panels, offers an ideal solution for strategic outdoor digital signage. With a pixel pitch of 5mm and a 2:1 aspect ratio, this display delivers exceptional brightness and ultra-high image quality, ensuring clear visibility even in bright environments. It’s a cost-effective option for those prioritizing frugality without compromising on performance.

$26,199.00

Add to wishlist
Compare

24 months warranty

In stock ready to ship

Technical support

Financing Available

GET A FREE QUOTE NOW!

Discover the perfect LED video wall for your project. Let’s create something amazing together. Contact us today for a free, no-obligation quote

Contact Form Demo

Description

Specification Details
Pixel Pitch 5mm
LED Configuration 3-in-1 SMD2121 LED / Nationstar encapsulation
Pixel Density 192 x 192 per panel
Panel Size 37.8” x 37.8” x 3.5” / 960 x 960 x 88mm
Module Quantity per Panel 18 (320 x 160mm each)
Weight per Panel 62 lbs / 30.9 Kg
Brightness 5500 NITS
Viewing Angle Horizontal 140° / Vertical 140°
Minimum Viewing Distance 25 ft / 7.6 m
Brightness Adjustment 0~100% (100 Levels)
Operating Life 100,000 Hours
Protection Level IP65 (Front and Back)
Max. Power Consumption 425W per panel
Ave. Power Consumption 240W per panel
Control Mode NovaStar Synchronous System
Refresh Rate 3840Hz
Frame Update Frequency 50-60Hz
Input Support Composite, S-Video, Component, VGA, DVI, HDMI, HD_SDI
Power Supply 100~240V 50-60Hz
Additional information
Outdoor

Size

Minimal Viewing Distance
